Castle Creations 060-0059-00 4-Pole Sensored Brushless 1406-7700KV Motor Only

Castle Creations 060-0059-00 Motor 4-Pole Sensored Brushless 1406-7700KV

This is the Castle Creations 1406 7700Kv Sensored Brushless Motor.
**NOT for use in 2WD or 4WD short course trucks.**

FEATURES

• Ideal upgrade for 1/10 scale on-road cars using 2s LiPos, may also be
• used in some lighter off-road 1/10 scale stadium trucks and
• buggies with conservative gearing
• Four magnet, four pole configuration for maximum efficiency at high
• RPM
• 1.4″ diameter slotted rotor
• High quality ball bearings

INCLUDES

• 1406 7700Kv Sensored Brushless Motor
• Sensor Wire
• Three 4mm Female Connectors

REQUIREMENTS

• Electronic Speed Control such as the Castle Creations Sidewinder
• SV3, CSEM0115, or Mamba Max Pro CSEM6600

SPECIFICATIONS

• Input Voltage Range: 2S LiPo, 6-8 cell NiMH
• Kv: 7700
• Max. RPM: 100,000
• Max. Recommended Vehicle Weight: 4lbs (1814g) with battery RTR
• Length: 1.9″ (49.5mm)
• Diameter: 1.4″ (36mm)
• Weight with Wires: 6.9oz (197g)
• Shaft Diameter: 1/8″ (3.17mm)
• Shaft Length: 0.59″ (15mm)
• Mounting Hole Specifications: M3 @ 25mm
• Connectors: 4mm Male Castle Bullet
